The MC300 can be placed upright on a table or shelf, standing on its own plastic feet.
The MC300 can be custom installed in a cabinet of your choice. The mounting panel cutout,
mounting shelf ventilation cutout and amplifier dimensions are shown on page 7.
It Is essential to cut out a ventilation hole In the mounting shelf according to the
dimensions In the drawing.
Always provide adequate ventilation for your MC300. The trouble free life of any electronic
instrument is greatly extended by providing sufficient ventilation for proper cooling. In a system
stack, the power amplifier should always be at the top. If all the components are installed in a
single cabinet, a quiet running ventilation fan can be a definite asset in maintaining all the system
components at their coolest possible operating temperatures.
Provide at least a 1-1/2" (3.8cm) above the heat sink area to allow the free flow of air. Cutout
a ventilation hole in the mounting shelf corresponding to the dimensions in the drawing. The
recommended minimum depth for mounting, including clearance for connectors is 17-1/2"
(44.5cm). Allow 1-1/8" (2.9cm) in front of the mounting panel for knob clearance.
6
INSTALLATION
