McIntosh MC302 Service Manual

43 44
RIGHT TERMINAL 751226 SCH
9
J1
1
1
R AUTOFORMER
.15µF
C1
2 5 W
R1
1
.047µF
C2
4
R2
7
J5:1
7
7
RED
YEL
BLU
8 4
2
J2
J3
FB 2
GND
FB 8
HEATSINKR
1
R FB8
R FB2
R (+)
R (+)
RIGHT OUTPUTS
BP1 BP2 BP3 BP4
J4
J5:3
J5:5

McIntosh MC302 Specifications

General

Damping factor	40
Amplifier class	-
Frequency range	10 - 100000 Hz
RMS rated power	600 W
Audio output channels	2.0 channels
Peak power per channel	300 W
Signal-to-Noise Ratio (SNR)	122 dB
Total Harmonic Distortion (THD)	0.005 %
XLR in	Yes
Speakers connectivity type	Binding post
Product color	Black
Connectivity technology	Wired
Maximum current	6.6 A
AC input voltage	110 V
AC input frequency	50 - 60 Hz

Weight and Dimensions

Depth	558.8 mm
Width	444.5 mm
Height	239.7 mm
Weight	44450 g
