STEREO
CONNECTION
BRIDGED
MONOPHONIC
CONNECTION
LEFT
SPEAKER
4 OR 8
OHMS
RIGHT
SPEAKER
4 OR 8
OHMS
MUST BE IN
STEREO POSITION
FOR STEREO PROGRAMS
PREAMPLIFIER
8 OHM
SPEAKER
MUST BE IN
MONO POSITION
FOR MONO PROGRAMS
MONO
INPUT
SIGNAL
10
STEREO
MONO
STEREO
MONO

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the McIntosh MC7100 and is the answer not in the manual?

McIntosh MC7100 Specifications

General IconGeneral
Total Harmonic Distortion0.005%
Input Sensitivity1.0V
Input Impedance20k ohms
Power GuardYes
Power Output per Channel100 Watts
Frequency Response20Hz to 20kHz (+0 -0.25dB)
