McIntosh MP1100 - Page 32

58
Ref. No. Description Part No.
RIGHT AUDIO PCB 751909 (Cont’d.)
Ref. No. Description Part No.
PARTS LIST (Cont’d.)
2
C97 CAP MONO .1uF 50V +/-20% X7R SMD 061365
C98 CAP MONO .1uF 50V +/-20% X7R SMD 061365
C99 CAP MONO .1uF 50V +/-20% X7R SMD 061365
C100 CAP 47pF 200V 10% NPO SMD0805 061368
C101 CAP 47pF 200V 10% NPO SMD0805 061368
C102 CAP 47pF 200V 10% NPO SMD0805 061368
C103 CAP MONO .1uF 50V +/-20% X7R SMD 061365
C104 CAP 100pF 200V 5% SMD0805 061390
C105 CAP 100pF 200V 5% SMD0805 061390
C106 CAP 100pF 200V 5% SMD0805 061390
C107 CAP MONO .1uF 50V +/-20% X7R SMD 061365
C108 CAP NPO 200pF 5% 50V SMD0805 061413
C109 CAP NPO 200pF 5% 50V SMD0805 061413
C110 CAP NPO 200pF 5% 50V SMD0805 061413
C111 CAP MONO .1uF 50V +/-20% X7R SMD 061365
C112 CAP MONO .1uF 50V +/-20% X7R SMD 061365
C113 CAP 47pF 200V 10% NPO SMD0805 061368
C114 CAP 47pF 200V 10% NPO SMD0805 061368
C115 CAP 47pF 200V 10% NPO SMD0805 061368
C116 CAP ELECT 1500UF 6.3V 20% 066629
C117 CAP ELECT 1500UF 6.3V 20% 066629
C118 CAP ELECT 1500UF 6.3V 20% 066629
C119 CAP ELECT 1500UF 6.3V 20% 066629
C120 CAP ELECT 1500UF 6.3V 20% 066629
C121 CAP ELECT 1500UF 6.3V 20% 066629
C122 CAP ELECT 100UF 25V 066573
C123 CAP ELECT 100UF 25V 066573
C124 CAP NPO 1000pF 100V 5% SMD0805 061391
C125 CAP NPO 1000pF 100V 5% SMD0805 061391
C126 CAP NPO 1000pF 100V 5% SMD0805 061391
C127 CAP MONO .1uF 50V +/-20% X7R SMD 061365
C128 CAP MONO .1uF 50V +/-20% X7R SMD 061365
C129 CAP MONO .1uF 50V +/-20% X7R SMD 061365
C130 CAP MONO .1uF 50V +/-20% X7R SMD 061365
C131 CAP MONO .1uF 50V +/-20% X7R SMD 061365
C132 CAP MONO .1uF 50V +/-20% X7R SMD 061365
C133 CAP ELECT 47UF 25V 20% BP 066556
C134 CAP ELECT 47UF 25V 20% BP 066556
C135 CAP ELECT 47UF 25V 20% BP 066556
C136 CAP ELECT 100UF 25V 066573
C137 CAP ELECT 100UF 25V 066573
C138 CAP ELECT 100UF 25V 066573
C139 CAP ELECT 100UF 25V 066573
C140 CAP 470pF 100V 10% NPO SMD0805 061370
C141 CAP ELECT 47UF 35V SMD 066604
C142 CAP ELECT 47UF 35V SMD 066604
C143 CAP MONO .1uF 50V +/-20% X7R SMD 061365
C145 CAP NPO 1000pF 100V 5% SMD0805 061391
C146 CAP NPO 1000pF 100V 5% SMD0805 061391
D1 DIODE ESD SUPPRESSOR SMD 070198
D2 DIODE ESD SUPPRESSOR SMD 070198
D3 DIODE ESD SUPPRESSOR SMD 070198
D4 DIODE ZENER 5.1V 5% SMD 070215
D5 DIODE SMALL SIGNAL 4148 SMD 070199
D6 DIODE SMALL SIGNAL 4148 SMD 070199
D7 DIODE SMALL SIGNAL 4148 SMD 070199
D8 DIODE SMALL SIGNAL 4148 SMD 070199
D9 DIODE SMALL SIGNAL 4148 SMD 070199
D10 DIODE SMALL SIGNAL 4148 SMD 070199
D11 DIODE SMALL SIGNAL 4148 SMD 070199
D12 DIODE SMALL SIGNAL 4148 SMD 070199
D13 DIODE SMALL SIGNAL 4148 SMD 070199
D14 DIODE SMALL SIGNAL 4148 SMD 070199
D15 DIODE SMALL SIGNAL 4148 SMD 070199
D16 DIODE SMALL SIGNAL 4148 SMD 070199
D17 DIODE SMALL SIGNAL 4148 SMD 070199
D18 DIODE ESD SUPPRESSOR SMD 070198
D19 DIODE ESD SUPPRESSOR SMD 070198
D20 DIODE ESD SUPPRESSOR SMD 070198
D21 DIODE SMALL SIGNAL 4148 SMD 070199
D22 DIODE SMALL SIGNAL 4148 SMD 070199
D23 DIODE SMALL SIGNAL 4148 SMD 070199
D24 DIODE SMALL SIGNAL 4148 SMD 070199
D25 DIODE SMALL SIGNAL 4148 SMD 070199
D26 DIODE SMALL SIGNAL 4148 SMD 070199
D27 DIODE SMALL SIGNAL 4148 SMD 070199
D28 DIODE SMALL SIGNAL 4148 SMD 070199
D29 DIODE SMALL SIGNAL 4148 SMD 070199
D30 DIODE SMALL SIGNAL 4148 SMD 070199
D31 DIODE ESD SUPPRESSOR SMD 070198
D32 DIODE ESD SUPPRESSOR SMD 070198
D33 DIODE ESD SUPPRESSOR SMD 070198
J1 CONN 18 PIN FFC SMD 118003
J2 JACK SINGLE RCA 118135
J3 CONN 12 PIN FFC SMD 118001
J4 CONNECTOR 3PIN HEADER 2MM 118013
J5 CONN XLR FEM HORIZ PCB LATCH 117814
J6 JACK SINGLE RCA 118135
J7 RECEPTACLE XLR MALE 117686
J8 JACK SINGLE RCA 118135
J9 JACK SINGLE RCA 118135
J10 JACK SINGLE RCA 118135
J11 CONN XLR FEM HORIZ PCB LATCH 117814
K1 RELAY REED DPST-NO 1.2A 5VDC 087089
K2 RELAY REED DPST-NO 1.2A 5VDC 087089
K3 RELAY REED DPST-NO 1.2A 5VDC 087089
K4 RELAY REED DPST-NO 1.2A 5VDC 087089
K5 RELAY REED DPST-NO 1.2A 5VDC 087089
K6 RELAY REED DPST-NO 1.2A 5VDC 087089
K7 RELAY REED DPST-NO 1.2A 5VDC 087089
K8 RELAY REED SPST-NO 5V 1.2A 087078
K9 RELAY REED SPST-NO 5V 1.2A 087078
K10 RELAY REED SPST-NO 5V 1.2A 087078
K11 RELAY REED SPST-NO 5V 1.2A 087078
K12 RELAY REED SPST-NO 5V 1.2A 087078
K13 RELAY REED SPST-NO 5V 1.2A 087078
K14 RELAY REED DPST-NO 1.2A 5VDC 087089
K15 RELAY REED DPST-NO 1.2A 5VDC 087089
K16 RELAY REED DPST-NO 1.2A 5VDC 087089
K17 RELAY REED DPST-NO 1.2A 5VDC 087089
K18 RELAY REED DPST-NO 1.2A 5VDC 087089
L1 FERRITE 1500 OHMS 1A SMD 122464
L2 FERRITE 1500 OHMS 1A SMD 122464
L3 FERRITE 1500 OHMS 1A SMD 122464
PCB1 PC BD RIGHT AUDIO 130333
Q1 TRANS PNP W/R1R2 10K/10K SMD 132348
Q2 TRANSISTOR NPN A05 SMD 132333
Q3 TRANSISTOR NPN A05 SMD 132333
