7
2. Open the turntable inner carton and remove the top
foam pad. Refer to figure 2.
3. Carefully lift up on the sides of the turntable and
remove it from the turntable inner carton.
4. Open the turntable platter/accessory carton and
remove the the turntable platter. Refer to Figure 3
Unpacking the Turntable
Unpacking the Turntable
To protect the fine finish of the MT10 Precision Turn-
table during the assembly and adjustment process, it is
advisable to prepare a suitable clean working area with
a soft, clean fabric, such as a bed linen or blanket.
It is recommended that the Professionals at your
McIntosh Dealer, who are skilled in all aspects of in-
stallation and operation, unpack, assemble, adjust and
install the MT10 Precision Turntable and any associ-
ated audio equipment.
CAUTION: To prevent possible damage to the turntable
platter bearing, do not move the MT10 Pre-
cision Turntable with the platter installed.
1. After opening the outer shipping carton, carefully
remove the turntable inner carton (which has two
foam end caps) and the turntable platter/accessory
inner carton. Refer to figure 1.
Outer
Shipping
Carton
Turntable Carton
Turntable Platter/
Accesory Carton
Accessories Box
Figure 3
Turntable Platter
Top foam pad
Tur ntable
Figure 2
5. Open the accessories box and check to make sure
the following items are inside:
A. McIntosh MCC10 Moving Coil Cartridge.
B. AC / DC Adapter with plug adapters.
C. Tonearm Counter Weight.
D. Turntable Record Clamp.
E. Turntable Bubble Level.
F. Assembly/Adjustment Tools.
G. Cartridge Mounting Hardware.
H. Pair of cloth gloves.
I. Turntable Bearing Oil (full-synthetic).
J. Tone Arm Height Gauge (used for MCC10
Car tridge).
K. Protractor.
M. Cloth Dust Cover.
N. Turntable Platter Mat.
Note: The Turnable Platter Mat is located in an
album cover and in the Turntable Platter/
Accessory Carton.
6. Proceed to Assembly of the Turntable starting on
the next page.
