IOMM AGR AGR 055A through 100A 17
Table 10, 60 Hz, Single Point Power Electrical Data
Minimum POWER SUPPLY Max. Fuse
AGR Circuit Field Wire Conduit Hub or
Unit Volts Ampacity Wire Nominal HACR Breaker
Size (MCA) Quantity Gauge Quantity Size Size
208 237 3 250 1 2.00 300
230 237 3 250 1 2.00 300
055A 380 137 3 1/0 1 1.50 175
460 117 3 #1 1 1.00 150
575 90 3 #3 1 1.00 125
208 271 3 300 1 2.50 350
230 258 3 300 1 2.50 350
060A 380 150 3 1/0 1 1.50 200
460 133 3 1/0 1 1.50 175
575 98 3 #3 1 1.00 125
208 298 3 350 1 2.50 400
230 275 3 300 1 2.50 350
065A 380 160 3 2/0 1 1.50 225
460 146 3 1/0 1 1.50 200
575 104 3 #2 1 1.25 125
208 322 3 400 1 2.50 450
230 300 3 350 1 2.50 400
070A 380 190 3 3/0 1 2.00 250
460 153 3 2/0 1 1.50 200
575 114 3 #2 1 1.25 150
208 351 3 500 1 3.00 450
230 329 3 400 1 2.50 450
075A 380 220 3 4/0 1 2.00 300
460 163 3 2/0 1 1.50 225
575 126 3 #1 1 1.50 150
208 384 6 3/0 2 2.00 500
230 373 3 500 1 3.00 500
080A 380 240 3 250 1 2.50 300
460 187 3 3/0 1 2.00 250
575 151 3 2/0 1 1.50 200
208 411 6 4/0 2 2.00 500
230 408 6 4/0 2 2.00 500
085A 380 256 3 300 1 2.50 350
460 206 3 4/0 1 2.00 250
575 171 3 3/0 1 2.00 225
208 411 6 4/0 2 2.00 500
230 408 6 4/0 2 2.00 500
090A 380 256 3 300 1 2.50 350
460 206 3 4/0 1 2.00 250
575 171 3 3/0 1 2.00 225
208 461 6 250 2 2.00 600
230 458 6 4/0 2 2.00 600
095A 380 269 3 300 1 2.50 350
460 220 3 4/0 1 2.00 300
575 176 3 3/0 1 2.00 225
208 501 6 250 2 2.00 700
230 498 6 250 2 2.00 700
100A 380 279 3 300 1 2.50 350
460 231 3 250 1 2.00 300
575 180 3 3/0 1 2.00 250
All Electrical Data notes are on page 20
