Product Manual ALR2-3 ALR 110F – 150F 13
Table 5, ALR 110F - 150F, R-22, SI Units
AMBIENT AIR TEMPERATURE
25°C (77°F) 30°C (86°F) 35°C (95°F) 40°C (104°F) 45°C (113°F)
ALR
SIZE
LWT
(°C)
Capac.
kW
PWR
kWi
COP
Capac.
kW
PWR
kWi
COP
Capac.
kW
PWR
kWi
COP
Capac.
kW
PWR
kWi
COP
Capac.
kW
PWR
kWi
COP
5.0 (41.0°F) 412.8 100.4 3.6 392.0 109.1 3.2 369.8 117.7 2.8 346.6 126.3 2.5 325.1 134.8 2.2
6.0 (42.8°F) 424.5 101.6 3.7 403.6 110.6 3.2 381.4 119.4 2.8 357.6 128.3 2.5 335.0 137.1 2.2
7.0 (44.6°F) 438.2 102.8 3.7 415.4 112.1 3.3 393.7 121.1 2.9 368.5 130.3 2.5 344.9 139.4 2.2
8.0 (46.4°F) 450.7 103.9 3.8 427.1 113.5 3.3 404.8 122.9 2.9 378.9 132.2 2.6 354.7 141.7 2.3
9.0 (48.2°F) 461.9 105.0 3.9 437.7 114.9 3.4 414.8 124.6 3.0 388.4 134.2 2.6 363.8 144.1 2.3
110F
10.0 (50.0°F) 478.3 106.2 3.9 454.2 116.5 3.5 429.2 126.2 3.0 403.5 136.2 2.7 378.2 146.4 2.3
5.0 (41.0°F) 455.3 107.6 3.5 432.3 117.0 3.1 407.8 126.1 2.7 382.2 135.4 2.4 358.5 144.5 2.1
6.0 (42.8°F) 468.2 108.9 3.6 445.0 118.6 3.2 420.6 128.0 2.8 394.4 137.5 2.4 369.4 147.0 2.2
7.0 (44.6°F) 483.3 110.1 3.6 458.1 120.2 3.2 434.2 129.9 2.8 406.4 139.6 2.5 380.3 149.4 2.2
8.0 (46.4°F) 497.0 111.4 3.7 471.0 121.7 3.3 446.4 131.7 2.9 417.9 141.7 2.5 391.1 151.9 2.2
9.0 (48.2°F) 509.3 112.6 3.8 482.7 123.2 3.3 457.5 133.6 2.9 428.3 143.8 2.6 401.1 154.4 2.3
120F
10.0 (50.0°F) 527.5 113.9 3.9 500.8 124.8 3.4 473.3 135.3 3.0 445.0 146.0 2.6 417.0 156.9 2.3
5.0 (41.0°F) 482.7 117.9 3.6 458.3 128.1 3.2 432.3 138.2 2.8 405.2 148.3 2.5 380.1 158.3 2.2
6.0 (42.8°F) 496.3 119.3 3.6 471.8 129.9 3.2 445.9 140.2 2.8 418.1 150.7 2.5 391.6 161.1 2.2
7.0 (44.6°F) 512.3 120.7 3.7 485.6 131.7 3.2 460.3 142.3 2.9 430.8 153.0 2.5 403.2 163.7 2.2
8.0 (46.4°F) 526.9 122.1 3.8 499.3 133.3 3.3 473.3 144.3 2.9 443.0 155.3 2.6 414.7 166.4 2.2
9.0 (48.2°F) 540.0 123.3 3.8 511.7 135.0 3.4 485.0 146.3 2.9 454.1 157.6 2.6 425.3 169.2 2.3
130F
10.0 (50.0°F) 559.2 124.7 3.9 531.0 136.8 3.4 501.8 148.3 3.0 471.7 160.0 2.6 442.1 171.9 2.3
5.0 (41.0°F) 497.9 124.6 3.5 472.8 135.5 3.1 446.0 146.1 2.7 418.0 156.8 2.4 392.1 167.4 2.1
6.0 (42.8°F) 512.0 126.1 3.6 486.7 137.4 3.2 460.0 148.3 2.8 431.4 159.3 2.4 404.0 170.3 2.2
7.0 (44.6°F) 528.5 127.6 3.6 501.0 139.2 3.2 474.9 150.4 2.8 444.5 161.7 2.5 416.0 173.1 2.2
8.0 (46.4°F) 543.5 129.0 3.7 515.1 141.0 3.3 488.3 152.6 2.9 457.0 164.2 2.5 427.8 176.0 2.2
9.0 (48.2°F) 557.0 130.4 3.8 527.9 142.7 3.3 500.3 154.7 2.9 468.5 166.6 2.6 438.7 178.9 2.3
135F
10.0 (50.0°F) 576.9 131.9 3.9 547.8 144.6 3.4 517.7 156.7 3.0 486.7 169.2 2.6 456.1 181.7 2.3
5.0 (41.0°F) 520.1 130.8 3.4 493.9 142.2 3.0 465.9 153.3 2.7 436.7 164.6 2.4 409.6 175.6 2.1
6.0 (42.8°F) 534.9 132.3 3.5 508.5 144.2 3.1 480.6 155.6 2.7 450.6 167.2 2.4 422.0 178.7 2.1
7.0 (44.6°F) 552.1 133.9 3.6 523.3 146.1 3.2 496.0 157.9 2.8 464.3 169.7 2.5 434.5 181.7 2.2
8.0 (46.4°F) 567.8 135.4 3.7 538.1 147.9 3.3 510.0 160.1 2.9 477.4 172.3 2.5 446.9 184.7 2.2
9.0 (48.2°F) 581.9 136.9 3.8 551.4 149.8 3.3 522.7 162.4 2.9 489.4 174.8 2.6 458.3 187.8 2.3
140F
10.0 (50.0°F) 602.7 138.4 3.9 572.2 151.8 3.4 540.8 164.5 3.0 508.4 177.5 2.6 476.4 190.7 2.3
5.0 (41.0°F) 533.4 133.4 3.5 506.4 145.0 3.1 477.7 156.4 2.7 447.8 167.8 2.4 420.1 179.1 2.1
6.0 (42.8°F) 548.5 134.9 3.6 521.4 147.0 3.2 492.8 158.7 2.8 462.1 170.5 2.4 432.8 182.2 2.2
7.0 (44.6°F) 566.2 136.5 3.7 536.7 149.0 3.2 508.7 161.0 2.8 476.1 173.1 2.5 445.6 185.2 2.2
8.0 (46.4°F) 582.2 138.1 3.7 551.8 150.8 3.3 523.0 163.3 2.9 489.6 175.7 2.5 458.2 188.3 2.2
9.0 (48.2°F) 596.7 139.5 3.8 565.5 152.7 3.3 536.0 165.6 2.9 501.8 178.3 2.6 470.0 191.4 2.3
145F
10.0 (50.0°F) 618.0 141.1 3.9 586.8 154.7 3.4 554.5 167.7 3.0 521.3 181.0 2.6 488.6 194.5 2.3
5.0 (41.0°F) 556.7 139.6 3.5 528.6 151.7 3.1 498.6 163.6 2.7 467.3 175.6 2.4 438.4 187.4 2.1
6.0 (42.8°F) 572.5 141.2 3.6 544.2 153.8 3.2 514.3 166.0 2.8 482.3 178.4 2.4 451.7 190.7 2.2
7.0 (44.6°F) 590.9 142.9 3.7 560.1 155.9 3.2 530.9 168.5 2.8 496.9 181.1 2.5 465.1 193.9 2.2
8.0 (46.4°F) 607.7 144.5 3.7 575.9 157.9 3.3 545.9 170.9 2.9 511.0 183.9 2.5 478.3 197.1 2.2
9.0 (48.2°F) 622.8 146.0 3.8 590.2 159.8 3.3 559.4 173.3 2.9 523.7 186.6 2.6 490.5 200.4 2.3
150F
10.0 (50.0°F) 645.0 147.7 3.9 612.4 162.0 3.4 578.8 175.5 3.0 544.1 189.5 2.6 509.9 203.5 2.3
NOTES:
1. Ratings based on HCFC-22, evaporator fouling of 0.0176, evaporator temperature drop of 5.6°C and sea level altitude.
2. For 208V units multiply capacity and COP by 0.98.
3. For units with SpeedTrol option multiply capacity and COP by 0.99.
4. Interpolation is allowed; extrapolation is not permitted. Consult McQuay for performance outside the cataloged ratings.
5. kWi input is for compressors only. COP is for the entire unit, including compressors, fan motors and control power.
6. For LWT of 5°C and below please refer to application considerations for reciprocating chillers.
