Product Manual ALR2-3 ALR 110F – 150F 27
Physical Data
Table 15, Physical Data ALR 110F through 135F
ALR MODEL NUMBER
PHYSICAL DATA
110F 120F 130F 135F
BASIC DATA Ckt.1 Ckt.2 Ckt.1 Ckt.2 Ckt.1 Ckt.2 Ckt.1 Ckt.2
Unit Capacity @ ARI Conditions, Tons (kW) (1) 110.9 (388.1) 122.2 (427.7) 129.6 (453.6) 133.7 (468.0)
Number Of Refrigerant Circuits 2 2 2 2
Unit Operating Charge, R-22, Lbs. 115 115 120 120 120 120 120 120
Unit Operating Charge, R-22, (kg) (52.1) (52.1) (54.4) (54.4) (54.4) (54.4) (54.4) (54.4)
Cabinet Dimensions, LxWxH, In. 229 x 83 x 89 229 x 83 x 89 229 x 83 x 89 229 x 83 x 89
Cabinet Dimensions, LxWxH, (mm) (5809 x 2118 x 2210) (5809 x 2118 x 2210) (5809 x 2118 x 2210) (5817 x 2118 x 2210)
Unit Operating Weight, Lbs. (kg) 9700 (4394) 9880 (4476) 9880 (4476) 9880 (4476)
Unit Shipping Weight, Lbs. (kg) 9420 (4267) 9550 (4326) 9550 (4326) 9550 (4326)
Add'l Weight If Copper Finned Coils, Lbs. (kg) 1370 (620) 1370 (620) 1370 (620) 1370 (620)
COMPRESSORS
Type Semi-Hermetic Semi-Hermetic Semi-Hermetic Semi-Hermetic
Nominal Horsepower 30-30 30-35 30-35 35-35 35-35 35-35 35-40 35-40
Number Of Cylinders Per Compressor 6 - 6 6 - 6 6 - 6 6 - 6 6 - 6 6 - 6 6 - 6 6 - 6
Oil Charge Per Compressor, oz. 140 - 140 140 - 140 140 - 140 140 - 140 140 - 140 140 - 140 140 - 255 140 - 255
Oil Charge Per Compressor, (l) (4.1 – 4.1) (4.1 – 4.1) (4.1 – 4.1) (4.1 – 4.1) (4.1 – 4.1) (4.1 – 4.1) (4.1 – 6.5) (4.1 – 6.5)
CAPACITY REDUCTION STEPS - PERCENT OF COMPRESSOR DISPLACEMENT
Staging - Circuit #1 in Lead 0-16-32-40-48 0-15-32-39-48 0-17-33-42-50 0-16-32-40-48
-64-84-92-100 -67-84-91-100 -67-83-92-100 -66-84-92-100
Staging - Circuit #2 in Lead 0-16-32-40-48 0-17-32-41-48 0-17-33-42-50 0-16-32-40-48
-68-84-92-100 -65-84-91-100 -67-83-92-100 -66-84-92-100
CONDENSERS - HIGH EFFICIENCY FIN AND TUBE TYPE WITH INTEGRAL SUBCOOLING
Coil Face Area,Sq. Ft. 115 115 115 115 115 115 115 115
Coil Face Area, (M
2
) (10.3) (10.3) (10.3) (10.3) (10.3) (10.3) (10.3) (10.3)
Finned Height x Finned Length, In. 80 x 208 80 x 208 80 x 208 80 x 208 80 x 208 80 x 208 80 x 208 80 x 208
Finned Height x Finned Length, (mm)
(2032 x
5283)
(2032 x
5283)
(2032 x
5283)
(2032 x
5283)
(2032 x
5283)
(2032 x
5283)
(2032 x
5283)
(2032 x
5283)
Fins Per Inch x Rows Deep 16 x 3 16 x 3 16 x 3 16 x 3 16 x 3 16 x 3 16 x 3 16 x 3
Maximum Relief Valve Pressure Setting, psig (kPa) 450 (3103) 450 (3103) 450 (3103) 450 (3103) 450 (3103) 450 (3103) 450 (3103) 450 (3103)
CONDENSER FANS - DIRECT DRIVE PROPELLER TYPE
Number Of Fans - Fan Diameter, In. (mm) 10 - 28 (711) 10 - 28 (711) 12 - 28 (711) 12 - 28 (711)
Number Of Motors - HP (kW) 10 - 1.5 (1.1) 10 - 1.5 (1.1) 12 - 1.5 (1.1) 12 - 1.5 (1.1)
Fan And Motor RPM, 60 Hz 1140 1140 1140 1140
60 Hz Fan Tip Speed, FPM 8357 8357 8357 8357
60 Hz Total Unit Airflow, CFM 90200 90200 108240 108240
DIRECT EXPANSION EVAPORATOR - BAFFLED SHELL AND THRU-TUBE
Diameter, in. - Length, in. 12.8 x 94.6 14.0 x 95.5 14.0 x 95.5 14.0 x 95.5
Diameter, (mm) - Length, (mm) 325 x 2403 356 x 2426 356 x 2426 356 x 2426
Water Volume, Gallons, (L) 34 (127) 40 (150) 40 (150) 40 (150)
Maximum Water Pressure, psig (kPa) 152 (1047) 152 (1047) 152 (1047) 152 (1047)
Maximum Refrigerant Working Pressure, psig (kPa) 300 (2066) 300 (2066) 300 (2066) 300 (2066)
Water Inlet / Outlet Victaulic Connections, In. (mm) 5 (127) 8 (203) 8 (203) 8 (203)
Drain - NPT int, In. (mm) .5 (12.7) .5 (12.7) .5 (12.7) .5 (12.7)
Vent - NPT int, In. (mm) .5 (12.7) .5 (12.7) .5 (12.7) .5 (12.7)
NOTE:
1. Nominal capacity based on R-22, 95°F ambient air and 54°F/44°F water range.
