Product Manual ALR2-3 ALR 110F – 150F 45
Specifications
NOTE: Specifications are available on disk from the local McQuay Representative
SECTION 15XXX
AIR-COOLED RECIPROCATING CHILLERS
ALR 110F-ALR 150F
PART 1 - GENERAL
1.01 SUMMARY
Section includes design, performance criteria, refrigerants, controls, and installation
requirements for air-cooled reciprocating compressor packaged chillers.
1.02 REFERENCES
Comply with applicable Standards/Codes of ARI 550/590-98, ANSI/ASHRAE 15, ETL, CETL,
ASME Section VIII, ASHRAE Standard 90.1, NEC, and OSHA as adopted by the State.
1.03 SUBMITTALS
A. Submit shop drawings and product data in accordance with the specifications.
B. Submittals shall include the following:
1. Dimensioned plan and elevation view drawings, required clearances, and
location of all field connections.
2. Summary of all auxiliary utility requirements such as: electricity, water,
compressed air, etc. Summary shall indicate quality and quantity of each
required utility.
3. Single line schematic drawing of the power field hookup requirements,
indicating all items that are furnished.
4. Schematic diagram of control system indicating points for field
interface/connection. Diagram shall fully delineate field and factory wiring.
5. Certification of factory run test of chiller unit signed by company officer.
6. Installation manuals.
