Product Manual ALR2-3 ALR 110F – 150F 23
Table 13, ALR 110F - 150F, Field Wiring Data, Single Point Power
Wiring to
Standard Power Block
Wiring to Optional Factory Mounted
Disconnect Switch
ALR
Unit
Size
Volts
Terminal
Amps
Connector Wire Range/Phase
(Copper Wire Only)
Terminal
Amps
Connector Wire Range/Phase
(Copper Wire Only)
208 840 (2 qty.) 1/0 - 600 MCM 600 (2 qty.) 250 - 500 MCM
230 840 (2 qty.) 1/0 - 600 MCM 600 (2 qty.) 250 - 500 MCM
460 335 (1 qty.) #4 - 400 MCM 400 (1 qty.) 250 - 500 MCM
110F
575 335 (1 qty.) #4 - 400 MCM 250 (1qty.) #4 - 350 MCM
208 840 (2 qty.) 1/0 - 600 MCM 600 (2 qty.) 250 - 500 MCM
230 840 (2 qty.) 1/0 - 600 MCM 600 (2 qty.) 250 - 500 MCM
460 335 (1 qty.) #4 - 400 MCM 400 (1 qty.) 250 - 500 MCM
120F
575 335 (1 qty.) #4 - 400 MCM 250 (1qty.) #4 - 350 MCM
208 840 (2 qty.) 1/0 - 600 MCM N/A
230 840 (2 qty.) 1/0 - 600 MCM N/A
460 335 (1 qty.) #4 - 400 MCM 400 (1 qty.) 250 - 500 MCM
130F
575 335 (1 qty.) #4 - 400 MCM 250 (1qty.) #4 - 350 MCM
208 840 (2 qty.) 1/0 - 600 MCM N/A
230 840 (2 qty.) 1/0 - 600 MCM N/A
460 335 (1 qty.) #4 - 400 MCM 400 (1 qty.) 250 - 500 MCM
135F
575 335 (1 qty.) #4 - 400 MCM 250 (1qty.) #4 - 350 MCM
208 840 (2 qty.) 1/0 - 600 MCM N/A
230 840 (2 qty.) 1/0 - 600 MCM N/A
460 335 (1 qty.) #4 - 400 MCM 400 (1 qty.) 250 - 500 MCM
140F
575 335 (1 qty.) #4 - 400 MCM 400 (1 qty.) 250 - 500 MCM
208 840 (2 qty.) 1/0 - 600 MCM N/A
230 840 (2 qty.) 1/0 - 600 MCM N/A
460 335 (1 qty.) #4 - 400 MCM 400 (1 qty.) 250 - 500 MCM
145F
575 335 (1 qty.) #4 - 400 MCM 400 (1 qty.) 250 - 500 MCM
208 840 (4 qty.) 1/0 - 600 MCM N/A
230 840 (4 qty.) 1/0 - 600 MCM N/A
460 840 (2 qty.) 1/0 - 600 MCM 400 (1 qty.) 250 - 500 MCM
150F
575 840 (2 qty.) 1/0 - 600 MCM 400 (1 qty.) 250 - 500 MCM
See page 25 for other Electrical Data notes.
