McQuay MAC 150 C

Schematic Diagram
Refrigerant Circuit Diagram
Cooling Only (MAC030C/035C)
Cooling Only (MAC040C/050C/065C/070C)
Ref r i ger ant Fl ow Di r edt i on
5、Wat er Pump
4、BPHE
1、Compr essor
Chilled Wat er Out
LEGEND
Chilled Wat er I n
2、Heat Exchanger Fan 3、 Cool i ng Cap. Tube
6、Wat er Fl ow Swi t ch
7、Accumul at or
1、 Compr essor
4、 BPHE
LEGEND
5、 Wat er Pump
Refrigerant Fow Direction
Chilled Wat er I n
Chilled Wat er Out
2、 Heat Exchanger Fan 3、 Cool i ng Cap. Tube
6、 Wat er Fl ow Swi t ch
Page 46
