McQuay MAC 150 C Installation And Maintenance

Heat Pump (MAC080CR/100CR/120CR/150CR)
Ref r i ger ant Fl ow Di r ect i on When Heat i ng
7、Heat i ng Cap. Tube
11、Wat er Pump
3、Accumul at or
Ref r i ger ant Fl ow Di r ect i on When Cool i ng
1、Compr essor
9、Recei ver
LEGEND
2、Four Way Val ve
6、Cool i ng Cap. Tube
10、BPHE
12、Wat er Fl ow Swi t ch
4、Copper Tube Al uminium Fin
Heat Exchanger
8、Check Val ve
Chilled Wat er
In
Chilled Wat er
Out
Page 49

McQuay MAC 150 C Specifications

General

Brand	McQuay
Model	MAC 150 C
Category	Chiller
Language	English
