OMM TGZ-1 TGZ 040A through TGZ 190A 11
Table 5, Connection Sizes, Single Point Power Supply, Without External Overloads
Power Block Terminal Factory Installed Disconnect Factory Installed HSCCR
Power Block or
Bus Bar Lugs
Disconnect Switch
Molded Case
Disconnect Switch
(Circuit Breaker )
Circ. Brkr Connection (2)
TGZ
Unit
Size
Volts
Freq.
(Hertz)
Size (1)
Connection (2)
Wire Range - CU
Switch
Size (1)
Connection (2)
Wire Range - CU
Size (1) Wire Range - CU
208 380 #4 - 500 kcmil 250 #6 - 350 kcmil 250 #6 - 350 kcmil
230 380 #4 - 500 kcmil 250 #6 - 350 kcmil 250 #6 - 350 kcmil
460 175 #14 - 2/0 100 #10 - 1/0 150 #6 - 350 kcmil
040
575
60
175 #14 - 2/0 100 #10 - 1/0 90 #10 - 1/0
208 380 #4 - 500 kcmil 250 #6 - 350 kcmil 350 (2) 3/0 - 500 kcmil
230 380 #4 - 500 kcmil 250 #6 - 350 kcmil 350 (2) 3/0 - 500 kcmil
460 175 #14 - 2/0 125 #3 - 3/0 175 #6 - 350 kcmil
050
575
60
175 #14 - 2/0 100 #10 - 1/0 150 #6 - 350 kcmil
208 380 #4 - 500 kcmil 250 #6 - 350 kcmil 400 (2) 3/0 - 500 kcmil
230 380 #4 - 500 kcmil 250 #6 - 350 kcmil 400 (2) 3/0 - 500 kcmil
460 175 #14 - 2/0 125 #3 - 3/0 200 #6 - 350 kcmil
060
575
60
175 #14 - 2/0 100 #10 - 1/0 150 #6 - 350 kcmil
208 380 #4 - 500 kcmil 400 (2) 3/0 - 500 kcmil 400 (2) 3/0 - 500 kcmil
230 380 #4 - 500 kcmil 400 (2) 3/0 - 500 kcmil 400 (2) 3/0 - 500 kcmil
460 175 #14 - 2/0 250 #6 - 350 kcmil 225 #6 - 350 kcmil
080
575
60
175 #14 - 2/0 125 #3 - 3/0 175 #6 - 350 kcmil
208 380 #4 - 500 kcmil 400 (2) 3/0 - 500 kcmil 600 (2) 3/0 - 500 kcmil
230 380 #4 - 500 kcmil 400 (2) 3/0 - 500 kcmil 600 (2) 3/0 - 500 kcmil
460 175 #14 - 2/0 250 #6 - 350 kcmil 250 #6 - 350 kcmil
100
575
60
175 #14 - 2/0 250 #6 - 350 kcmil 200 #6 - 350 kcmil
208 380 #4 - 500 kcmil 400 (2) 3/0 - 500 kcmil 600 (2) 3/0 - 500 kcmil
230 380 #4 - 500 kcmil 400 (2) 3/0 - 500 kcmil 600 (2) 3/0 - 500 kcmil
460 380 #4 - 500 kcmil 250 #6 - 350 kcmil 300 (2) 3/0 - 500 kcmil
110
575
60
175 #14 - 2/0 250 #6 - 350 kcmil 250 #6 - 350 kcmil
208 760 (2) #2 - 500 kcmil 600 (2) 3/0 - 500 kcmil 700 (2) 3/0 - 500 kcmil
230 760 (2) #2 - 500 kcmil 600 (2) 3/0 - 500 kcmil 700 (2) 3/0 - 500 kcmil
460 380 #4 - 500 kcmil 250 #6 - 350 kcmil 400 (2) 3/0 - 500 kcmil
120
575
60
175 #14 - 2/0 250 #6 - 350 kcmil 300 (2) 3/0 - 500 kcmil
208 760 (2) #2 - 500 kcmil 600 (2) 3/0 - 500 kcmil 800 (3) 1/0 - 500 kcmil
230 760 (2) #2 - 500 kcmil 600 (2) 3/0 - 500 kcmil 800 (3) 1/0 - 500 kcmil
460 380 #4 - 500 kcmil 250 #6 - 350 kcmil 400 (2) 3/0 - 500 kcmil
150
575
60
380 #4 - 500 kcmil 250 #6 - 350 kcmil 300 (2) 3/0 - 500 kcmil
208 760 (2) #2 - 500 kcmil 600 (2) 3/0 - 500 kcmil 1000 (3) 1/0 - 500 kcmil
230 760 (2) #2 - 500 kcmil 600 (2) 3/0 - 500 kcmil 1000 (3) 1/0 - 500 kcmil
460 380 #4 - 500 kcmil 400 (2) 3/0 - 500 kcmil 450 (2) 3/0 - 500 kcmil
170
575
60
380 #4 - 500 kcmil 250 #6 - 350 kcmil 350 (2) 3/0 - 500 kcmil
208 760 (2) #2 - 500 kcmil 800 (3) 1/0 - 500 kcmil 1000 (3) 1/0 - 500 kcmil
230 760 (2) #2 - 500 kcmil 800 (3) 1/0 - 500 kcmil 1000 (3) 1/0 - 500 kcmil
460 380 #4 - 500 kcmil 400 (2) 3/0 - 500 kcmil 500 (2) 3/0 - 500 kcmil
190
575
60
380 #4 - 500 kcmil 400 (2) 3/0 - 500 kcmil 400 (2) 3/0 - 500 kcmil
NOTES:.
1. "Size" is the maximum amperage rating for the terminals or the main electrical device...
2. "Connection" is the range of wire sizes that the terminals on the electrical device will accept.
