56 TGZ 040A through TGZ 190A OMM TGZ-1
Screen Definitions – MENU
Top level menu:
< ALARM
< VIEW
< SET
<
ALARM menu:
ALARM < ACTIVE
< LOG
<
<
VIEW menu:
VIEW < COMPRESSOR
< UNIT
< EVAPORATOR
< FANS/TOWER
VIEW UNIT menu:
VIEW < TEMP
UNIT < STATUS
< REFRIGERANT
SET menu:
SET < ALARM LIMITS
< UNIT SPs
< COMPRESSOR SPs
< FANS/TOWER SPs
Screen Definitions – VIEW
View Unit Status
VIEW UNIT STATUS (1)
Auto
Cooling Stage = 0
Evap Pump = RUN
Unit states can be OFF, COOL, GYLCOL, or ALARM as determined from the Unit Mode
setpoint, the Unit Enable, and the presence of an alarm.
Circuit states can be OFF/OFF, ON/OFF, OFF/ON, and ON/ON.
Evaporator Pump States can be OFF, STRT, or RUN.
When more than one screen are stacked (i.e., relate to each other on the same subject), they
are numbered sequentially with the numbers appearing in the upper-right corner.
VIEW UNIT STATUS (2)
Demand Limit=Stg 4
Network Limit=Stg 4
