OMM TGZ-1 TGZ 040A through TGZ 190A 57
VIEW UNIT STATUS (3)
Stg Up Delay=XXX sec
Stg Dn Delay=XXX sec
Ice Delay=XXh XXm
VIEW UNIT STATUS (4)
D.O. 111111111
123456789012345678
000000000000000000
This menu gives the status of digital outputs (D.O.), 1=ON, 0=OFF. Numbers are 1 through
18. See Table 12 on page 26 for number reference.
VIEW UNIT STATUS (5)
D.I. 111111111
123456789012345678
000000000000000000
This menu gives the status of digital inputs (D.I.), 1=ON, 0=OFF. Numbers are 1 through
18. See
Table 11
on page 25 for number reference.
VIEW UNIT STATUS (6)
Analog Output
(volts x 100)
1 = 000.0 2 =
000.0
VIEW UNIT STATUS (7)
Analog Output
(volts x 100)
3 = 000.0 4 =
000.0
VIEW UNIT STATUS (8)
EXB1 Online
D.O. 1 2 3 4
0 0 0 0
View Unit Tempertures
TGZ, Cooling Mode TGZ, Heating Mode
VIEW UNIT TEMP (1) VIEW UNIT TEMP (1)
Evap LWT = XX.X°
°°
°F
Cond LWT = XX.X°
°°
°F
Cond EWT = XXX.X°
°°
°F
Cond EWT = XXX.X°
°°
°F
LWT Target = XX.X°
°°
°F
LWT Target = XX.X°
°°
°F
VIEW UNIT TEMP (2)
LWT Rate= XX.X °
°°
°F
Control Band= XX.X°
°°
°F
To Next Page
