q
A-A
A
A
q
R
x
51
33-MAINTENANCE AND CLEANING
Technical Dept. - All rights reserved - Reproduction prohibited
CLEANING THE GLASS
It is recommended to clean the ceramic glass with a dry brush, or if it is very dirty, spray a little specic detergent and clean with a cloth.
ATTENTION!
Do not use abrasive products and do not spray the glass cleaning product on the painted parts and on the door
gaskets (ceramic bre seal).
CHECKING CLEANLINESS OF THE COMBUSTION CHAMBER AND GLASS
On compact products such as pellet inserts, where the ame is enclosed in a very contained and performing combustion chamber, the
quality of the unburnt products, often due to the quality of the fuel and the installation, can cause the glass and chamber to become dirty
more quickly. Mainly to improve cleanliness of the glass, where total cleanliness will never be possible due to the nature of the pellet fuel,
you can simply act on the front deector, increasing the space between the deector and the glass.
Loosen the two screws “x” (the outer ones) fastening the deector “R” shown in the diagram and push the deector 2/3 mm towards the
back of the combustion chamber. Tighten the screws back in.
Before losing the references, it is advisable to measure the distance “q” between the outside of the deector “R” and the cast iron rebox
back and then push the deector “R” 2/3 mm towards the back.
Caution! Make sure you keep the deector “R” parallel with the glass of the rebox door.
