Parts List
Fig No.
Part No.
Description
4
161-10026
Combustion air inlet tube ø25mm
5
161-10027
Stainless steel exhaust tube ø25mm
6
520-00005
20-32mm stainless steel hose clamp
7
161-10030
Muffler
8
523-00003
Fastening clamp for Combustion air inlet tube R-type ø27mm
9
161-10021
Nylon oil hose ø4mm×1.25mm
10
161-10022
Rubber oil hose ø3.5mm x 3mm
11
520-00004
8-10 mini hose clamp
12
161-10023
Jacket for oil pump
13
161-10025
Strapping tape
14
520-00011
50-70 stainless steel hose clamp
15
161-10028
Hot air outlet tube ø60
16
161-10029
Air outlet for DA2 ø60
17
161-10036
Air inlet filter
18
161-10033
Wiring harness
19
161-10035
10 Litre fuel tank
20
161-10034
Fixed plate
Caution
Safety!
Never pack items around the diesel heater unit. Always ensure all items are clear of the heater unit
and all hoses and exhaust
Ensure intake and output vents are always clear and free of obstruction
Always allow the heater unit to cool under ventilation mode before turning off unit
Never use the diesel heater in a confined area e.g. Garage, shed, workshop, non-ventilated area
Consider the comfort of nearby campers and the effect of exhaust fumes
Danger!
Risks of injury and burns
The motor unit and exhaust operate at high temperatures. Do not attempt to work on the unit while hot
Do not allow children to operate the heater
****Allow the heater to fully cool, turn off power before refuelling
Do not smoke near diesel fuel tank
Do not modify the diesel heater unit in any way.
Do not inhale exhaust fumes
The heater exhaust is very hot. Do not use the diesel heater where contact with long grass and
vegetation is possible. Always use in a cleared area.
Never use the heater while the trailer is in motion.
