Kitchen
To extend the kitchen from the caravan, release pad bolt (g1) and press down the blue slide tab (g 2) and pull kitchen
out. The kitchen will lock into place when extended. To put kitchen away, again press down the blue tabs and push back
into place.
To connect the gas, plug the gas bayonet into the outlet
pictured below.
Always use the support leg when the kitchen is extended
Fig1 Fig2
CAUTION – Use of the slide out kitchen cooktop without the annex or awning
may adversely affect the safety and operation of the appliance.
CAUTION
