56
Parts List
Fig No. Part No. Description Size
4 161-10026 Combustion air inlet tube 25mm
5 161-10027 Stainless steel exhaust tube 25mm
6 520-00005 20-32mm stainless steel hose clamp
7 161-10030 Mufer
8 523-00003 Fastening clamp for Combustion air inlet tube R-type 27mm
9 161-10021 Nylon oil hose 4mm×1.25mm
10 161-10022 Rubber oil hose 3.5mm x 3mm
11 520-00004 8-10 mini hose clamp
12 161-10023 Jacket for oil pump
13 161-10025 Strapping tape
14 520-00011 50-70 stainless steel hose clamp
15 161-10028 Hot air outlet tube 60
16 161-10029 Air outlet for DA2 60
17 161-10036 Air inlet lter
18 161-10033 Wiring harness
19 161-10035 10 Litre fuel tank
20 161-10034 Fixed plate
Caution
Safety!
• Never pack items around the diesel heater unit. Always ensure all items are clear of the heater unit and all hoses
and exhaust.
• Ensure intake and output vents are always clear and free of obstruction.
• Always allow the heater unit to cool under ventilation mode before turning off unit.
• Never use the diesel heater in a conned area e.g., Garage, shed, workshop, non-ventilated area
• Consider the comfort of nearby caravans and the effect of exhaust fumes.
Danger!
Risks of injury and burns.
• The motor unit and exhaust operate at high temperatures. Do not attempt to work on the unit while
hot
• Do not allow children to operate the heater.
• ****Allow the heater to fully cool, turn off power before refuelling.
• Do not smoke near diesel fuel tank.
• Do not modify the diesel heater unit in any way.
• Do not inhale exhaust fumes.
• The heater exhaust is very hot. Do not use the diesel heater where contact with long grass and vegetation is
possible. Always use in a cleared area.
• Never use the heater while the trailer is in motion.
