MDS E-PGM+ - ISP Connection Overview; ISP Connection Diagram

MDS
19
8-2. Info. : ISP Connections
Note1) If other signals affect the communication in ISP mode,
disconnect them with pins by using jumper or switch.
DSCL/CLK/SWD_CLK
GND
MCU
VDD
RST/VPP
Writer
DSCL
VDD
GND
ISP mode
user mode
Vdd
User Application Board
Note1)
Note1)
user reset
circuit
VPP/Reset
switch
Writer
•
DSDA/DATA/SWD_DATA
DSDA
