USB-1608G User's Guide Specifications
21
Environmental
Table 14. Environmental specifications
Parameter
Specification
Operating temperature range
0 °C to 55 °C max
Storage temperature range
–40 °C to 85 °C max
Humidity
0% to 90% non-condensing max
Mechanical
Table 15. Mechanical specifications
Parameter
Specification
Dimensions (L × W × H)
127 × 89.9 × 35.6 mm (5.00 × 3.53 × 1.40 in.)
User connection length
3 m (9.84 ft) max
Screw terminal connector
Table 16. Screw terminal connector specifications
Parameter
Specification
Connector type
Screw terminal
Wire gauge range
16 AWG to 30 AWG
Differential mode pinout
Table 17. 8-channel differential mode pinout
Pin
Signal name
Pin description
Pin
Signal name
Pin description
1
CH0H
AI channel 0 HI
28
CH7L
AI channel 7 LO
2
CH0L
AI channel 0 LO
29
CH7H
AI channel 7 HI
3
AGND
Analog ground
30
AGND
Analog ground
4
CH1H
AI channel 1 HI
31
CH6L
AI channel 6 LO
5
CH1L
AI channel 1 LO
32
CH6H
AI channel 6 HI
6
AGND
Analog ground
33
AGND
Analog ground
7
CH2H
AI channel 2 HI
34
CH5L
AI channel 5 LO
8
CH2L
AI channel 2 LO
35
CH5H
AI channel 5 HI
9
AGND
Analog ground
36
AGND
Analog ground
10
CH3H
AI channel 3 HI
37
CH4L
AI channel 4 LO
11
CH3L
AI channel 3 LO
38
CH4H
AI channel 4 HI
12
AGND
Analog ground
39
AGND
Analog ground
13
NC
No connection
40
AGND
Analog ground
14
AGND
Analog ground
41
AGND
Analog ground
15
NC
No connection
42
+5V
+5V power output
16
AGND
Analog ground
43
AGND
Analog ground
empty
empty
17
GND
Digital ground
44
GND
Digital ground
18
DIO0
DIO channel 0
45
AICKI
AI clock input
19
DIO1
DIO channel 1
46
AICKO
AI clock output
20
DIO2
DIO channel 2
47
NC
No connection
21
DIO3
DIO channel 3
48
NC
No connection
22
DIO4
DIO channel 4
49
TRIG
Trigger input
23
DIO5
DIO channel 5
50
GND
Digital ground
24
DIO6
DIO channel 6
51
CTR1
Counter 1 input
25
DIO7
DIO channel 7
52
CTR0
Counter 0 input
26
GND
Digital ground
53
TMR
Timer output
27
NC
No connection
54
GND
Digital ground
