USB-1608G User's Guide Specifications
22
Single-ended mode pinout
Table 18. 16-channel single-ended mode pinout
Pin
Signal name
Pin description
Pin
Signal name
Pin description
1
CH0
AI channel 0
28
CH15
AI channel 15
2
CH8
AI channel 8
29
CH7
AI channel 7
3
AGND
Analog ground
30
AGND
Analog ground
4
CH1
AI channel 1
31
CH14
AI channel 14
5
CH9
AI channel 9
32
CH6
AI channel 6
6
AGND
Analog ground
33
AGND
Analog ground
7
CH2
AI channel 2
34
CH13
AI channel 13
8
CH10
AI channel 10
35
CH5
AI channel 5
9
AGND
Analog ground
36
AGND
Analog ground
10
CH3
AI channel 3
37
CH12
AI channel 12
11
CH11
AI channel 11
38
CH4
AI channel 4
12
AGND
Analog ground
39
AGND
Analog ground
13
NC
No connection
40
AGND
Analog ground
14
AGND
Analog ground
41
AGND
Analog ground
15
NC
No connection
42
+5V
+5V power output
16
AGND
Analog ground
43
AGND
Analog ground
empty
empty
17
GND
Digital ground
44
GND
Digital ground
18
DIO0
DIO channel 0
45
AICKI
AI clock input
19
DIO1
DIO channel 1
46
AICKO
AI clock output
20
DIO2
DIO channel 2
47
NC
No connection
21
DIO3
DIO channel 3
48
NC
No connection
22
DIO4
DIO channel 4
49
TRIG
Trigger input
23
DIO5
DIO channel 5
50
GND
Digital ground
24
DIO6
DIO channel 6
51
CTR1
Counter 1 input
25
DIO7
DIO channel 7
52
CTR0
Counter 0 input
26
GND
Digital ground
53
TMR
Timer output
27
NC
No connection
54
GND
Digital ground
