Mebay DC30C - Alarm Protection; Parameters

DC30C User Manual
6
 Successful start Times;
 Current running time;
 Total running time;
 Classes maintenance notice.
4. Alarm protection
 Over speed;
 Under speed ;
 Low oil pressure ;
 High temperature;
 External emergency alarm;
 Sensor Open;
 Over Frequency;
 Under Frequency;
 Over voltage;
 Under voltage;
 Over current;
 Low water level alarm;
 Emergency Stop;
 Crank failure;
 Stop Failure;
 Over battery voltage;
 Under Battery voltage.
5. Parameters
Options
Parameters
Operation Voltage
DC8-36V Continuous
Power Consumption
Standby：24V：MAX 1W
Working：24V：MAX 2W
AC Voltage Input
1P2W(L-N input) 30VAC-360VAC(ph-N)
Operation Voltage
DC8-36V Continuous
Fuel Relay Output
1Amp DC+VE Supply voltage
Start Relay Output
1Amp DC+VE Supply voltage
Programmable Relay output 1
1Amp DC+VE Supply voltage
Programmable Relay output 2
1Amp DC+VE Supply voltage
Programmable Relay output 3
1Amp DC+VE Supply voltage
Switch value input
Connected to battery negative pole effective
Working condition
-25-65℃
Storage condition
-40-85℃
Protection Level
IP54：when waterproof rubber gasket is added
between controller and its panel
Insulation strength
Apply AC1.5kV voltage between high voltage terminal
and low voltage terminal; The leakage current is not
more than 3mA within 1min.
Overall dimension
106mm×86mm×45mm
Panel cutout
78mm×66mm
Weight
0.25Kg
