Mebay DC5 D MK3 Series User Manual

DC5xD MK3 GENSET CONTROLLER USER MANUAL
32
NO
Parameter
Range(defaults)
Notes
1
Primary Modes
STOP
Manual
Auto
Auto save
The primary modes on power, easy for user
operation.
Note: auto record function can not record the
mode with load.
2
Manual crank
times
1-30 (1 time)
Crank times under manual mode and test
mode.
3
Auto start crank
times
1-30 (3 times)
Crank times under auto mode.
4
E.T.S. hold times
1-10(2 times)
The max E.T.S. hold on power shall be
canceled once stop success under auto
mode . the output interval time is " Fail to stop
".
5
Crank disconnet
RPM
Hz
Oil pressure(delay)
RPM/Frequency
RPM/Oil Pressure
Frequency/Oil
Pressure
RPM/Frequency/Oil
press.
1.If there is no oil pressure sensor, please
dont choose it.
2.Oil pressure switch input is not the crank
condition
3.Please check if the running status, stop
condition are according with crank condition.
4.Means either of the conditions can be
acceptable as crank condition. But all of them
should be meet together to regard as stop
condition.
6
Frequency
disconnect
0-200%(28%)
Rated frequency multiplying by this value is
regarded as crank success condition. When
the gens frequency is over the condition
value, then system regards it as crank
success.
7
Oil pressure
disconnect
0-400kpa(200kpa)
When the engine oil pressure is over the
condition value, then system regards it as
crank success, motor escaped.
8
RPM disconnect
0-200%(24%)
Rated RPM multiplying by this value is
regarded as crank success condition. When
the RPM is over the condition value, then
system regards it as crank success, motor
escaped.
9
OP pre-supply
stop
50-600kpa(200kpa)
When the oil pressure is over the condition
value, then pre-oil supply is stopped.
10
RPM-up stop
0-200%(90%)
Rated RPM multiplying by this value is
regarded as speed-up stop value. When the
RPM is over this value, then the RPM-Up
procession is stopped in time.
11
Temperature-up
stop
20-200℃(68 ℃ )
When the temperature is over the preset
value, then temperature-up procession is
stopped in time.
12
Voltage-up stop
0-200%(85%)
Rated voltage multiplying by this value is
regarded as voltage-up stop value. When the
voltage is over this value, then the voltage-Up
procession is stopped in time.
13
Fuel pump open
0-100%(25%)
When the fuel level is lower than preset value
