DC5xD MK3 GENSET CONTROLLER USER MANUAL
33
and remains 10S, fuel pump opened signal
output
When the fuel level is higher than preset value
and remains 1S, fuel pump closed signal
output.
When it is set as 5000, then this function is
disabled.
When it is set as 2000/01/01, this function is
disabled.
The action after the primary maintenance
expired.
When the battery voltage is lower than start
value and remains 10s under non-running
status, then the relay is opened. When it is
higher than the close value and remains 10s,
relay is closed. Once coming into running
mode, there is no output.
When it is set to enabled, when the generator
set meets the closing conditions, it will be
loaded automatically.
3)Delay time setting
The time during the genset starts after the mains
failure or remote signal is valid.
The time needed to be preheat before the starter on
power.
Under pre-oil supply, if the oil pressure is higher
than setting value, then pre-oil supply stopped.
The time when the starter is on power.
If crank failure, the waiting time before the second
test time.
When the crank condition contains oil pressure, if
the oil pressure is higher than the preset value and
continue for few seconds, then it is regarded as
crank success.
Low oil pressure, high temperature, under speed,
under frequency, under voltage, charge failure are
all invalid during this time except for emergency
stop ,over speed, over freq.
Idle running time when crank successfully.
The longest speed-up time,during which time the
system will exit once speed increased successfully .
The longest warming-up time,during which time the
system will exit once temperature increased
successfully .
The longest voltage-up time,during which time the
system will exit once voltage increased
successfully .
The time needed for loading.
