DC5xD MK3 GENSET CONTROLLER USER MANUAL
36
NO
Parameter
Range(defaults)
Notes
1
Over freq alarm
0-200%(114%)
Rated frequency multiplying by this value is
regarded as under over frequency alarm value.
When the Freq is higher than the value and comes
into over freq delay but still higher (emergency faults
delay), then over frequency alarms.If the value is set
as 200, then the alarm is disabled.
2
Under freq
alarm
0-200%(80%)
Rated frequency multiplying by this value is
regarded as under frequency alarm value. When the
Freq is lower than the value and comes into under
freq delay but still lower (normal faults delay), then
under frequency alarms.If the value is set as 0, then
the alarm is disabled.
3
Over voltage
warning
0-200%(120%)
Rated voltage multiplying by this value is regarded
as over voltage alarm value. When the voltage is
higher than the value and comes into over voltage
delay but still higher (normal faults delay), then over
voltage alarms.If the value is set as 200, then the
alarm is disabled.
4
Under voltage
alarm
0-200%(80%)
Rated voltage multiplying by this value is regarded
as under voltage alarm value. When the voltage is
lower than the value and comes into under voltage
delay but still lower (normal faults delay), then under
voltage alarms.If the value is set as 0, then the
alarm is disabled.
5
Phase current
over-load alarm
0-200%(100%)
Rated current multiplying by this value is regarded
as over current alarm value. When the current is
higher than the value and comes into over current
delay but still higher (over current faults delay), then
over current alarms.If the value is set as 200, then
the alarm is disabled.
6
Non-balance
current ratio
warning
10-100%(100%)
It is valid for 2P3W or 3P4W.When the non-balance
current ratio is higher than the value and comes into
delay but still higher(normal warn delay), then non-
balance current ratio warns.If the value is set as
100, then the warning is disabled.
7
Over total
power alarm
0-200%(100%)
Rated power multiplying by this value is regarded as
over power alarm value. When the loading power is
higher than the value and comes into delay but still
higher (power faults delay), then over power
alarms..If the value is set as 200, then the alarm is
disabled.
6)Output / Input setting
NO
Parameters
Range(defaults)
Notes
1
AUX. OUTPUT 1
(Functional of PIN
6)
0-50
( 17. E.S.T. hold)
0. Disable.
1. Public warning output: when there is any
warning output.
2. Public alarm output: when there is any
alarm output, alarm locks till revert back.
3. Audio alarm: when there is any alarm
2
AUX. OUTPUT 2
(Functional of PIN
7,8,9)
0-50
(10.Idle speed
control)
