output, the Audio controls.
4. Shades control: there is output once
genset starts and stop till stable.
5. Preheat mode 1: preheat before start.
6. Pre-oil supply control: Under pre-oil
supply,if the oil pressure is higher than
setting value or pre-oil supply time ends,
then pre-oil supply stopped.
7. Fuel output: output once gens starts and
off till stable.
8. Crank output: output once cranking, no
output in other mode.
9. Genset running: output under running,off
once RPM is lower than cranking RPM.
The crank success condition can be set.
10.Idle speed control 1: used for speed
controller, there is output under idle but no
output under high speed.
11.Speed-up control: during the procession
of speed increasing, the output time is the
Longest RPM-up time.
12.High speed control: The output is valid
after idle delay is completed, and the
output is closed after high-speed heat
dissipation.
13.Excitation output: there is output during
cranking procession and there is 2s output
if there is no frequency under high speed
status.
14.Gens load: continuous or pulse type
according to time setting.
15.Gens unload: continuous or pulse type
according to time setting.
16.Speed-down control: the output time is
shutdown idle delay during shutdown idle
or shutdown on power procession.
17.E.S.T. hold: shutdown output, it is used for
gens with stop solenoid. when the setting
value of shutdown delay is over, then it is
off.
18.System in stop: there is output under stop
mode.
19.System in manual: there is output under
manual mode.
20.System in auto: there is output under auto
mode.
21.Fuel pump output: there is output if the oil
capacity is lower than start condition for
10s and shutdown if it is higher than the
shutdown condition for 1s.
22.Battery charging control: there is output
