Mebay DC8-D MK Series User Manual

DC8xD MK3 GENSET CONTROLLER USER MANUAL
27
2-繁体中文
3-Español
4-Pусский
2
Gens poles
2/4/6/8(4)
When the flywheel teeth is set as 0,the
RPM will be resulted by frequency.
Pole 2: 50Hz---3000RPM.Pole 4:
50Hz---1500RPM.
Pole 6: 50Hz---1000RPM.Pole 8:
50Hz---750RPM
3
Gens AC system
Disable
1 phase 2 wire
2 phase 3 wire
3 phase 3 wire
3 phase 4 wire
Gens phases:
No gens parameters can be displayed
if setting as disable, which is applied
to water pump genset.
4
CT rate
5-6000A/5A
(500A/5A)
Used for setting genset CT primary
current, secondary rated current 5A.
5
Rated frequency
40.0-80.0Hz (50.0Hz)
Setting generator rated frequency to
choose the meter range and calculate
the alarm value.
6
Rated phase
voltage
80-360V(230V)
Setting generator phase voltage to
choose the meter range and calculate
the alarm value.
7
Rated phase
current
5-6000A(500A)
Setting generator phase current to
choose the meter range and calculate
the alarm value.
8
Rated total power
5-2000K (276Kw ）
Set total power of generator to choose
the meter range and calculate the
average loading rate and alarm value.
9
Rated battery
voltage
8.0-36.0V (24.0V)
Choose the meter range and calculate
the alarm value.
10
Rated RPM
500-4500RPM (1500)
Choose the meter range and calculate
the alarm value.
11
Flywheel teeth
0-300(0)
If the setting is 0, (RPM sensor
Disabled), then RPM is resulted by Hz.
12
Oil pressure
sensor
0:Disable
1:User defined-Resistance
2:User defined-Voltage
3:Volt In 1MPa-0-5V
4:Volt In 1MPa-0.5-4.5V
5: VDO 0-10Bar
6:MEBAY-003B
7:SGH
8:SGD
9:SGX
10:CURTIS
11:DATCON 10Bar
12:VOLVO-EC
13:3015237
14:WEICHAI 0-0.6MPa
15:GENCON 0-10Bar
Choose the usual oil pressure sensor,
if the sensor users choose is not the
10 types, it can be User-defined.
