DC8xD MK3 GENSET CONTROLLER USER MANUAL
7
 RPM Lost
 Sensor Open
 Over Frequency
 Under Frequency
 Over voltage
 Under voltage
 Over current
 Over power
 Maintenance expire
 Low water level alarm
 Emergency Stop
 Crank failure
 Stop Failure
4.Parameters
Options
Parameters
Working voltage
DC8V----36V Continuous
Power consumption
Standby：24V：MAX 1W
Working：24V：MAX 7W
AC Voltage Input
1P2W 30VAC-276VAC (ph-N)
2P3W 30VAC-276VAC (ph-N)
3P4W 30VAC-276VAC (ph-N)
Rotate speed sensor
Frequency
200-10000Hz
MAX Accumulating Time
99999.9Hours（Min Store time:6min）
Fuel Relay Output
Max 16Amp DC+VE Supply voltage
Start Relay Output
Max 16Amp DC+VE Supply voltage
AUX. OUPUT1
Max 5Amp DC+VE Supply voltage
AUX. OUPUT2
Max 5Amp DC+VE Supply voltage
AUX. OUPUT3
Max 5Amp DC+VE Supply voltage
AUX. OUPUT4
5AMP Non-contact normal close output
AUX. OUPUT5
5AMP Non-contact normal open output
Excitation output
Max 0.9AMP DC+VE supply voltage
Switch value input
Available if connecting with Battery -
Working condition
-25-65℃
Storage condition
-40-85℃
Protection Level
IP54：when waterproof rubber gasket is added between
controller and its panel
Insulation strength
Apply AC1.5kV voltage between high voltage terminal
and low voltage terminal; The leakage current is not
more than 3mA within 1min.
Overall dimension
241mm*177mm*45mm
Panel cutout
220mm*160mm
Weight
0.9Kg
