Page 138 SE
AC
Slab Series - Service & Parts Manual
March 2022Section 18 - Hydraulics
Item Part Number Description Qty.
1
41488 Lower Lift Cylinder (2632AC, 3346AC, 4046AC) 1
46405 Lower Lift Cylinder (4555AC) 1
2 44448 Pressure Sensor 1
3 42480 Plug 1
4
43370 Orifice (2632AC, 3346AC, 4046AC) 1
46406 Orifice (4555AC)
5 42821 Plug 1
6 43369 Check Valve 1
7 43638 Straight Fitting 1
8 43639 Elbow 1
9 43640 Tee Fitting 1
10 41162 Lowering Knob 1
11
41833 Emergency Down Cable Assembly (2632AC, 3346AC, 4046AC) 1
44988 Emergency Down Cable Assembly (4555AC) 1
12 50423 Screw SHCS M04-0.70 × 12 1
13 43365 Cable Connector 1
14 43364 Nut 1
15 41550 Coil 1
16 41363 Solenoid Valve Spool 1
17 53138 Screw SHCS M06-1.00 × 16 2
18 53046 WSHR M06 Spring Washer 2
19 50000 WSHR M06 Standard Flat Washer 2
20 41164 Valve Cover 1
21 41413 Nut 1
22 41166 Fitting 1
23 43361 Washer 2
24 41167 Fitting 1
25
41168 Seal Kit (2632AC, 3346AC, 4046AC) 1
44989 Seal Kit (4555AC) 1
To Next Page
