Page 4 Micro 13-XD - Operator’s Manual
July 2020
Machine Specifications
Working Height*
Indoor 19 ft 5.7 m
Outdoor 16 ft 4.8 m
Maximum Platform Height
Indoor 13 ft 3.9 m
Outdoor 10 ft 3 m
Maximum Drive Height
Indoor 13 ft 3.9 m
Outdoor 10 ft 3 m
Stowed Height
Top Guardrail 78 in 1.98 m
Platform Floor 35 in 0.9 m
Guardrail Height 43.3 in 1.1 m
Toeboard Height 6 in 15 cm
Machine Weight** (Unloaded) 2,050 lbs 930 kg
Maximum Lift Capacity 500 lbs 227 kg
Deck Extension Capacity 1 Person / 250 lbs (113 kg)
Xtra Deck Capacity 1 Person / 250 lbs (113 kg)
Maximum Occupants
Indoor (Xtra Deck Deployed) 1
Indoor (Xtra Deck Stowed) 2
Outdoor (Xtra Deck Deployed) 1
Outdoor (Xtra Deck Stowed) 1
Manual Force
Indoor 45 lbs 200 N
Outdoor 45 lbs 200 N
Length-Stowed (Overall) 58 in 1.5 m
Length-Stowed (Ladder Removed) 51 in 1.3 m
Platform Length (Extended) 75 in 1.9 m
Platform Length (Retracted) 51 in 1.3 m
Width (Overall) 30 in 76 cm
Platform Width (Outside) 27.5 in 70 cm
Wheel Base 41 in 1 m
Turning Radius - Inside 18 in 45 cm
Ground Clearance - Stowed 2.5 in 6 cm
Ground Clearance - Elevated 0.6 in 1.5 cm
Drive Speed (Proportional)
Stowed 0-2.5 mph 0-4.0 km/h
Raised Or Extended 0-0.7 mph 0-1.1 km/h
Gradability 25%/14°
Maximum Side Slope - Stowed 5°
Ground Pressure/Wheel 112 psi 7.9 kg/cm
2
Maximum Wheel Load 760 lbs 345 kg
Occupied Floor Pressure 234 psf 1,138 kg/m
2
Maximum Operating Wind Speed 28 mph / 12.5 m/sec (45 km/h)
Tire Size 9 × 3 inch / 230 × 80mm
Lug Nut Torque 19 Ft-lbs / 25.5 N-m, secured with cotter pin
Hydraulic Pressure 2,250 psi / 155 bar
Power System Voltage 24 Volt DC
Battery Charger
Input 110-230 V AC, 50-60 Hz
Output 24 Volt DC
Batteries Two 12-Volt deep cycle; 85Ah
Chassis Inclination 1.5 Side 3.0 Inline
Meets applicable requirements of ANSI A92.20-2020 & CSA B354.6-2019.
*Working Height adds 6 feet (2 m) to platform height.
**Weight may increase with certain options.
