Mec Micro 19-XD - Page 77

Page 73 Micro 19-XD - Service & Parts Manual
June 2020Section 17 - Electrical System
Item Part Number Description Qty.
1 42481 ECU Harness 1
2 42540 Accessories Harness 1
3 43755 Lowering Valve Harness 1
4 42484 Drive Motor Harness 1
5 41921 Pump Motor Positive Harness 1
6 41919 Pump Motor Negative Harness 1
7 41917 Motor Controller Harness 1
8 42485 DC Contactor Harness 1
9 42486 Fuse Harness 1
10 42487 Battery Positive Harness 1
11 42488 Battery Harness 1
12 42489 Battery Negative Harness 1
13 REF Ground Control Assembly (Refer To Page 48) 1
14 REF Pressure Sensor (Refer To Page 66) 1
15 REF Limit Switch, Pothole (Refer To Page 50) 2
16 REF Rotary Sensor (Refer To Page 50) 1
17 REF Tilt Sensor (Refer To Page 50) 1
18 REF Beacon (Refer To Page 50) 1
19 REF Platform Control Box Assembly (Refer To Page 60) 1
20 REF Hydraulic Power Unit (Refer To Page 44) 1
21 REF Horn (Refer To Page 42) 1
22 REF Alarm (Refer To Page 42) 1
23 REF Coil (Refer To Page 66) 1
24 REF Coil (Refer To Page 68) 1
25 REF Left Motor (Refer To Page 38) 1
26 REF Right Motor (Refer To Page 38) 1
27 REF Motor Controller (Refer To Page 46) 1
28 REF Motor (Refer To Page 44) 1
29 REF DC Contactor (Refer To Page 46) 1
30 REF 200A Fuse Assembly (Refer To Page 46) 1
31 REF Power Switch (Refer To Page 42) 1
32 REF Battery (Refer To Page 42) 2
33 REF Charger (Refer To Page 42) 1
34 42483
Harness, Communications 1
REF - Reference
