Page 35 Micro19 - Service & Parts Manual
October 2021Section 13 - Chassis
Item Part Number Description Qty.
1 41223 Steer Cylinder Assembly 1
-- 41594 Seal Kit 1
2 41298 Straight Fitting 2
3 41596 Cover 2
4 41794 Screw 2
5 41322 Cotter Pin 6
6 41321 Pin 2
7 41225 Bearing 4
8 43564 Washer 2
9 41210 Bearing 4
10 44607 Steer Yoke Weldment 1
11 42414 Wheel 2
12 41327 Washer 4
13 53347 Castle Nut M16 × 1.50 4
14 53348 Screw THMS M04-0.70 × 10 6
15 41323 Cover 2
16 41230 Bearing Cover 2
17 53269 Screw CSCS M05-0.80 × 16 8
18 41232 Key 2
19 42415 Wheel Shaft 2
20 41024 Bearing 4
21 41234 Connection Plate 2
22 50429 Screw HHCS M10-1.50 × 25 Serrated Flange 12
23 41328 Cap 2
24 53282 Screw CSCS M08-1.25 × 20 12
25 44608 Steer Yoke Weldment 1
26 41222 Bearing 2
27 42412 Tie Rod 1
28 50311 Nut NNYL M10-1.50 Flange 2
29 41792 Washer 2
30 41595 Bearing 4
To Next Page
