Mec Micro19 - Section 18 - Options; 900 W Inverter

Page 76 Micro19 - Service & Parts Manual
October 2021
900W Inverter
900W InverterMicro19
ART_5820
ILLUSTRATION No.
5 7
9
10
4
2
1
6
3
8
CONNECT TO INVERTER
GROUND.
CONNECT TO BATTERY POS
CONNECT TO
INVERTER RELAY
TERM #30
CONNECT TO RELAY #85
CONNECT TO INVERTER POS
CONNECT TO BATTERY GROUND
CONNECT TO INVERTER NEG
CONNECT TO RELAY #88
CONNECT TO THE BATTERY GROUND
CONNECT TO INVERTER NEG.
CONNECT TO POSITIVE SIDE OF THE
24 VOLT RELAY IN THE FRONT OF THE
COMPONENT TRAY
#87 WITH EXISTING WIRE
NOTE: ATTACH RELAY LEFT
OF CONTACTOR USING 50191
CONNECT POWER TO
PLATFORM CABLE HERE:
BROWN = LINE
BLUE = NEUTRAL
Y/G = GROUND
Section 18 - Options
900W Inverter
