Page 37 Micro19 - Service & Parts Manual
October 2021Section 13 - Chassis
Item Part Number Description Qty.
1 53263 Screw THMS M04-0.70 × 8 6
2 41323 Cover 2
3 53313 Nut NNYL M16 × 1.50 2
4 53314 WSHR M16 Flat Fender Washer 2
5 42414 Wheel 2
6 41239 Support 2
7 53315 Screw SHCS 3/8-24 × 1 1/4 8
8 53316 WSHR 3/8 Spring Washer 8
9 53317 WSHR 3/8 Standard Flat Narrow Washer 8
10 53268 Screw HHCS M10-1.50 × 30 Serrated Flange 8
11 41232 Key 2
12 42419 Right Drive Motor Assembly 1
-- 42886 Right Motor 1
-- 42889 Brake 1
-- 42887 Reducer 1
13 42421 Left Drive Motor Assembly 1
-- 42890 Left Motor 1
-- 42889 Brake 1
-- 42887 Reducer 1
14 53318 Screw PHMS M06-1.00 × 12 5
15 42407 Plate 1
-- 42883 Terminal Connector, Drive Motor Wires 2
