Page 39 Micro19 - Service & Parts Manual
October 2021Section 13 - Chassis
Item Part Number Description Qty.
1 42409 Pothole Guard Weldment 1
2 50430 Screw HHCS M10-1.50 × 45 4
3 41319 Linkage Weldment 1
4 41211 Pin 2
5 42410 Pothole Guard Weldment 1
6 41210 Bearing 4
7 41209 Pin 4
8 50311 Nut NNYL M10-1.50 Flange 8
9 42411 Pothole Link Plate 2
10 41214 Bearing 8
11 53349 Nut NNYL M14-2.00 Flange 6
12 41212 Gas Shock Strut 2
13 41215 Gas Shock 2
14 53283 Set Screw M05-0.80 × 10 Cone Point 2
15 41216 Pin 2
16 41217 Roller 2
17 41320 Linkage Weldment 1
18 44609 Pothole Guide 1
19 41203 Bearing 4
20 44610 Seal 2
21 41204 Pothole Hole Pusher Pin 2
22 44007 Adjusting Washer 2 2
23 44008 Adjusting Washer 3 2
24 44611 Pothole Hole Pusher Rod 2
