Mec Micro19 - Page 45

Page 41 Micro19 - Service & Parts Manual
October 2021Section 13 - Chassis
Item Part Number Description Qty.
1 42422 Hydraulic Power Unit (Refer To Page 42) 1
2 41413 Nut 1
3 41296 Straight Fitting 3
4 42491 Ground Control Cover 1
5 53350 Wing Nut M06-1.00 4
6 50000 WSHR M06 Standard Flat Washer 4
7 44019 Battery 2
8 41074 Alarm 1
9 53281 Nut NNYL M05-0.80 Flange 8
10 53351 Screw PHMS M05-0.80 × 16 8
11 43987 Towline 1
12 53352 Screw CSCS M06-1.00 × 10 4
13 42430 Towline Bracket 1
14 53273 Screw HHCS M06-1.00 × 14 Serrated Flange 2
15 42431 Press Plate 1
16 50568 Nut NNYL M06-1.00 Flange 9
17 REF Motor Controller Assembly (Refer To Page 44) 1
18 50359 Screw SHCS M05-0.80 × 16 4
19 53043 WSHR M05 Spring Washer 10
20 53038 WSHR M05 Standard Flat Washer 10
21 41075 Horn 1
22 43977 Latch 2
23 53264 Screw PHMS M06-1.00 × 20 4
24 53353 Screw PHMS M06-1.00 × 25 4
25 REF Ground Control Assembly (Refer To Page 46) 1
26 53348 Screw THMS M04-0.70 × 10 8
27 43988 Battery Tray Weldment 1
28 53263 Screw THMS M04-0.70 × 8 6
29 44612 Cover 1
30 53354 Screw PHMS M05-0.80 × 10 2
31 41575 Plug 1
32 41255 Glide Track 2
33 42071
Power Switch 1
34 42904 Charger 1
35 53222 Screw PHMS M05-0.80 × 8 4
36 53225 Screw CSCS M10-1.50 × 30 2
37 41337 Bracket 1
38 50002 WSHR M10 Standard Flat Washer 2
39 53054 WSHR M10 Spring Washer 2
40 50127 Screw SHCS M10-1.50 × 30 2
41 43978 Striker, Latch (Not Shown) 2
REF - Reference
