Page 43 Micro19 - Service & Parts Manual
October 2021Section 13 - Chassis
Item Part Number Description Qty.
1 42426 Tank 1
-- 43771 O-Ring, Tank Seal 1
2 43784 Tank Cover 1
3 42424 Motor 1
4 44009 Relief Valve 1
5 42425 Pump 1
-- 44855 O-Ring, Pump Seal 1
-- 44856 O-Ring, Pump-Face Seal 1
6 44010 Filter Web 1
7 43776 Plug 1
8 43777 Washer 1
9 44011 Coil 3
10 44013 Check Valve 1
11 41245 Solenoid Valve Spool 1
12 42427 Pressure Compensation Valve 1
13 44012 Relief Valve 1
14 41246 Solenoid Valve Spool 1
