Page 47 Micro19 - Service & Parts Manual
October 2021Section 13 - Chassis
Item Part Number Description Qty.
1 44536 Decal, Ground Control Panel 1
2 43990 Ground Control Panel Weldment 1
3 44580 Controller 1
4 50284 WSHR M04 Standard Flat Washer 4
5 50285 Nut NNYL M04 × 0.70 4
6 41334 Relay 24V 1
7 41070 Hour Meter 1
8 41419 Toggle Switch 1
9 41418 Key Switch 1
-- 91574 Key 1
10 41421 Indicator 1
11 43991 Brake Release Switch 1
12 41422 Emergency Stop Assembly 1
-- 43098 Red Mushroom Head 1
-- 43097 Base With 1 NC Contact 1
13 43992 Select Switch Assembly 1
-- 43993 Select Switch Head 1
-- 43994 Base With 1 NO Contact 1
-- 43096 NC Contact 1
