Page 49 Micro19 - Service & Parts Manual
October 2021Section 13 - Chassis
Item Part Number Description Qty.
1 41310 Beacon 1
2 41309 Beacon Cover 1
3 53223 Screw THMS M05-0.80 × 16 4
4 44613 Baffle Plate 1
5 53265 Screw THMS M05-0.80 × 10 7
6 43978 Lock Clasp 2
7 53173 Screw SHCS M05-0.80 × 10 6
8 53043 WSHR M05 Spring Washer 6
9 53038 WSHR M05 Standard Flat Washer 6
10 41197 Limit Switch 2
11 53113 Screw SHCS M04-0.70 × 16 4
12 53065 Screw SHCS M04-0.70 × 30 6
13 41315 Switch Cover 1
14 50423 Screw SHCS M04-0.70 × 12 4
15 53062 WSHR M04 Spring Washer 6
16 50284 WSHR M04 Standard Flat Washer 6
17 41198 Switch Cover 1
18 42401 Cover 1
19 44614 Frame Weldment 1
20 50289 Screw HHCS M06-1.00 × 40 2
21 41098 Tilt Sensor 1
22 42403 Sensor Bracket 1
23 50568 Nut NNYL M06-1.00 Flange 2
24 41003 Ground Strap 1
25 53273 Screw HHCS M06-1.00 × 14 Serrated Flange 1
26 44615 Ladder 1
27 50001 WSHR M08 Standard Flat Washer 4
28 53055 WSHR M08 Spring Washer 4
29 50031 Screw HHCS M08-1.25 × 25 4
30 41257 Bearing 2
31 41194 Sensor Bracket 1
32 41195 Rotary Sensor 1
33 44616
Cover 1
