Mec Micro19 - Page 55

Page 51 Micro19 - Service & Parts Manual
October 2021Section 14 - Scissor
Item Part Number Description Qty.
1 42437 Circlips 36
2 41354 Washer 34
3 41349 Pin 6
4 41576 Pin 1
5 41256 Platform Slider 2
6 44617 Inner Arm 4 1
7 41577 Pin 10
8 42454 Pin 1
9 53123 Screw SHCS M06-1.00 × 25 4
10 53046 WSHR M06 Spring Washer 4
11 50000 WSHR M06 Standard Flat Washer 4
12 42439 Lock Plate 2
13 42440 Pin 1
14 41345 Pin 2
15 42449 Pin 3
16 53256 Screw HHCS M06-1.00 × 16 Serrated Flange 3
17 50568 Nut NNYL M06-1.00 Flange 6
18 41262 Safety Arm Bushing 2
19 41263 Safety Arm 2
20 53255 Screw HHCS M06-1.00 × 20 Serrated Flange 2
21 53357 Screw HHCS M06-1.00 × 55 Flange 4
22 44801 Chassis Slider 2
23 41338 Pin 2
24 42446 Bearing 28
25 44802 Outer Arm 1 1
26 50386 Screw CSCS M06-1.00 × 25 4
27 41350 Pothole Pusher 1
28 44803 Inner Arm 1 1
29 41258 Pin 1
30 41112 Hydraulic Hoses Manifolds 1
31 43601 Hose 1
32 44015 Hose 1
33 43997
Hose 1
34 41114 Block 40
35 REF Lower Lift Cylinder Assembly (Refer To Page 66) 1
36 44050 Collar 3
37 53269 Screw CSCS M05-0.80 × 16 3
38 44804 Inner Arm 2 1
39 44805 Cable Bridge 2
40 44806 Inner Arm 3 1
41 REF Upper Lift Cylinder Assembly (Refer To Page 68) 1
42 42438 Cable Bridge 1
43 44807 Outer Arm 2 6
44 41287 Bearing 64
45 43744 Cable Bridge 1
