Page 57 Micro19 - Service & Parts Manual
October 2021Section 15 - Platform
Item Part Number Description Qty.
1 53281 Nut NNYL M05-0.80 Flange 4
2 43319 Manual Box 1
3 53223 Screw THMS M05-0.80 × 16 4
4 41283 Front Rail 1
5 50313 Nut NNYL M08-1.25 Flange 12
6 53409 Screw HHCS M08-1.25 × 80 Flange 4
7 53358 Screw HHCS M08-1.25 × 50 Flange 8
8 44586 Extension Deck Weldment 1
9 50038 Screw HHCS M12-1.50 × 25 2
10 53148 WSHR M12 Spring Washer 2
11 50003 WSHR M12 Standard Flat Washer 2
12 41140 Platform Locking Device Assembly (Refer To Page 58) 1
13 43618 Circlips 2
14 41131 Bearing 2
15 41141 Roller 2 2
16 53279 Screw CSCS M05-0.80 × 12 8
17 41284 Slide Pad 2
18 41360 Roller Bracket 2
19 53280 Screw CSCS M08-1.25 × 55 8
20 44812 Right Extension Rail 1
21 44800 Left Extension Rail 1
22 41120 Bumper 2
23 53378 Screw PHMS M05-0.80 × 12 2
To Next Page
