Page 65 Micro19 - Service & Parts Manual
October 2021Section 15 - Platform
Item Part Number Description Qty.
1 43819 Enclosure 1
2 43820 Control Box Bottom 1
3 43821 Clear Switch Actuator 4
4 43822 Circuit Bd Push Button 1
5 43823 Joystick 1
6 43835 Decal, Upper Control Box 1
7 43824 Coil Cord Assembly (Includes Connector) 1
8 43825 Continuous Tone Alarm, 6-28V 1
9 53306 HHMS 1/4-20 × 1/2 4
10 43826 Fastener, Thread Forming, Plastite #4 4
11 43827 E-Stop Button 1
12 43828 Switch Mount 1
13 94433 Single Contact Block, 1 NC, 22mm, Harmony XB4 1
