Page 67 Micro19 - Service & Parts Manual
October 2021Section 16 - Hydraulics
Item Part Number Description Qty.
1 41166 Fitting 1
2 43361 Washer 2
3 41167 Fitting 1
4 44832 Lower Lift Cylinder 1
5 42480 Plug 1
6 44448 Pressure Sensor 1
7 43638 Straight Fitting 1
8 43639 Elbow 1
9 43640 Tee Fitting 1
10 44003 Solenoid Valve Spool 1
11 41929 Coil 1
12 53361 Nut NHEX M06-1.00 1
13 50000 WSHR M06 Standard Flat Washer 2
14 42466 Screw 1
15 42465 Emergency Down Cable Assembly 1
16 41162 Lowering Knob 1
17 44833 Plate 1
18 44834 Support 1
19 53179 Screw HHCS M05-0.80 × 20 1
20 44004 Cable Connector 1
21 53362 Nut NHEX 1/2-20 UNF 1
22 42470 Seal Kit 1
23 43369 Check Valve 1
24 42821 Plug 1
25 43370 Orifice 1
26 41413 Nut 1
