Page 73 Micro19 - Service & Parts Manual
October 2021Section 17 - Electrical System
Item Part Number Description Qty.
1 42481 ECU Harness 1
2 44836 Pressure Sensor Harness 1
3 42540 Accessories Harness 1
4 43755 Lowering Valve 1
5 42484 Drive Motor Harness 1
6 41921 Pump Motor Positive Harness 1
7 44055 Pump Motor Negative Harness 1
8 41917 Motor Controller Harness 1
9 42485 DC Contactor Harness 1
10 42486 Fuse Harness 1
11 42487 Battery Positive Harness 1
12 42488 Battery Harness 1
13 42489 Battery Negative Harness 1
14 REF Ground Control Assembly (Refer To Page 46) 1
15 REF Pressure Sensor (Refer To Page 66) 1
16 REF Limit Switch, Pothole (Refer To Page 48) 2
17 REF Rotary Sensor (Refer To Page 48) 1
18 REF Tilt Sensor (Refer To Page 48) 1
19 REF Beacon (Refer To Page 48) 1
20 REF Platform Control Box Assembly (Refer To Page 62) 1
21 REF Hydraulic Power Unit (Refer To Page 42) 1
22 REF Horn (Refer To Page 40) 1
23 REF Alarm (Refer To Page 40) 1
24 REF Coil (Refer To Page 66) 1
25 REF Coil (Refer To Page 68) 1
26 REF Left Motor (Refer To Page 36) 1
27 REF Right Motor (Refer To Page 36) 1
28 REF Motor Controller (Refer To Page 44) 1
29 REF Motor (Refer To Page 42) 1
30 REF DC Contactor (Refer To Page 44) 1
31 REF 200A Fuse Assembly (Refer To Page 44) 1
32 REF Power Switch (Refer To Page 40) 1
33 REF
Battery (Refer To Page 40) 2
34 REF Charger (Refer To Page 40) 1
35 42483 Harness, Platform Control Box 1
REF - Reference
