Ride

Crash

Hi-Hat

Drum Module

Hi-Hat Control

Kick

Snare

Tom1

Tom2

Tom3

AFI Trigger

Setup

Caution!

To prevent electric shock and damage to drum module or other devices, always turn off the power of all devices

before making any connections.

Connecting Pads and Pedals

Standard configuration: KICK, SNARE (Double trigger), TOM 1~3, CRASH 1 (Choke), RIDE (Choke), HI-HAT,

HI-HAT CONTROL PEDAL, AFI Triggers.

Note:

1. Using the cables provided, connect each Trigger input jack on the rear panel of the module, and make sure

each pad is connected to its corresponding trigger input jack.

2. For details on assembling the drum stand, attaching the digital drum and connecting pads, refer to the

Installation Manual description.

CMY

AW_DD620_manual_G04_150508.pdf 8 2015/5/13 16:09:47
