Medeli DD630 - Setup; Connecting Pads and Pedals

8
Crash
Hi-Hat
Drum Module
Hi-Hat Control
Kick
Snare
Tom1
Tom2
Tom3
Setup
Caution!
To prevent electric shock and damage to drum module or other devices, always turn off the power of all devices
before making any connections.
Connecting Pads and Pedals
Standard configuration: KICK, SNARE (Double trigger), TOM 1~3, CRASH 1 (Choke), RIDE (Choke), HI-HAT,
HI-HAT CONTROL PEDAL.
Note:
1. Using the cables provided, connect each Trigger input jack on the rear panel of the module, and make sure
each pad is connected to its corresponding trigger input jack.
2. For details on assembling the drum stand, attaching the digital drum and connecting pads, refer to the
Installation Manual description.
Ride
