DRW-015 (GPI171)
Revised: 11/23/09
10
Backrest Assembly
1. Insert backrest into designated slot so that push-buttons are facing outward
(see Figure A).
2. Push buttons in and continue to insert backrest until buttons securely lock into
holes (see Figure B). Please note: There are 2 positions for the back rest. Adjust
according to your preference, but make sure both push buttons are protruding and
at the same level.
Notes: Make sure the brakes are locked before you lean against backrest.
Make sure push-buttons are completely protruding before leaning
against backrest.
Figure C
Figure B
Figure A
To Next Page
