Medline MDS86835 - Walker Components

DRW-015 (GPI171)
Revised: 11/23/09
Walker Components
Figure 1
Assembled Deluxe Rolling Walker
A. Hand Grips
B. Hand Brake Lock
C. Padded Seat
D. Padded Backrest
E. Triangular Hand Screw
F. 7" (17.8 cm) Front Wheels
G. Folding Hinge
H. 7" (17.8 cm) Rear Wheels
I. Brake Cable
J. Bag with Shoulder Strap
Figure 2 (E)
Triangular Hand Screw
4
A
B
C
D
E
H
G
F
I
Figure 3 (A & B)
Hand Grip & Brake
Front
Back
J
