TECHNICAL DATA
Engine type Air cooled, two-stroke
Displacement 42.7cm³
Output 1.2 kW
Idling speed 3000 ± 300/min
Spark plug L8RTC
Fuel tank capacity 1100 cm³
Max speed Clearing saw: 7800/min
Trimmer: 7300/min
Axle diameter Ø 26 mm
Clearing blade Ø 255 x 1.4 mm
Working width, trimmer spool 450 mm
Trimmer line Ø 2.8 mm
Weight 8 kg
Sound pressure level, LpA 96 dB(A), K = 3 dB
Measured sound power level, LwA
114 dB(A), K = 3 dB
Guaranteed sound power level, LwA
117 dB(A), K=3 dB
Max vibration level 6.6 m/s², K=1.5 m/s²
Always wear ear protection.
The declared vibration value, which has been
measured by a standardised test method, can be
used to compare dierent tools with each other
and for a preliminary assessment of exposure.
WARNING!
The actual vibration level when using power
tools may dier from the specied maximum
value, depending on how the tool is used. It is
therefore necessary to determine which safety
precautions are required to protect the user,
based on an estimate of exposure in actual
operating conditions (taking into account all
stages of the work cycle, e.g. the time when
the tool is switched o and when it is idling, in
addition to the start-up time).
DESCRIPTION
FIG. 1
1. Safety catch
2. Power switch
3. Throttle control B
4. Throttle control A
5. Guard
6. Gearbox
7. Trimmer head
8. Engine
9. Choke
10. Right handle
11. Left handle
12. Shaft coupling
13. Air lter cover
14. Screw for air lter cover
15. Flange
16. Clamp
17. Cover
18. Nut M8
19. Hex key
20. Ring spanner
21. Spanner
22. Fuel mix container
23. Strap
24. Fuel tank
25. Clearing blade
26. Blade guard
